const int weiche_anzahl = 4;
int servspeed = 20; // higher = slower
int debounce = 50;

typedef struct
{
int ledPin;
int buttonPin;
boolean currentState = LOW;//stroage for current button state
boolean lastState = LOW;//storage for last button state
boolean ledState = HIGH;//storage for the current state of the LED (off/on)
int servpos = 90;
int maxwinkel;
int minwinkel;
}WeicheStruct;

WeicheStruct weiche[weiche_anzahl];

Servo servo[weiche_anzahl];

void setup(){
servo[0].attach(0);
servo[1].attach(1);
servo[2].attach(2);
servo[3].attach(3);

weiche[0].ledPin = 4;
weiche[0].buttonPin = 8;
weiche[0].maxwinkel = 105;
weiche[0].minwinkel = 75;

weiche[1].ledPin = 5;
weiche[1].buttonPin = 9;
weiche[1].maxwinkel = 105;
weiche[1].minwinkel = 75;

weiche[2].ledPin = 6;
weiche[2].buttonPin = 10;
weiche[2].maxwinkel = 105;
weiche[2].minwinkel = 75;

weiche[3].ledPin = 7;
weiche[3].buttonPin = 11;
weiche[3].maxwinkel = 105;
weiche[3].minwinkel = 75;

for (int i=0; i<weiche_anzahl; i++) { pinMode(weiche[i].buttonPin, INPUT_PULLUP);//this time we will set the pin as INPUT pinMode(weiche[i].ledPin, OUTPUT); } } void loop(){ weiche[0].currentState = digitalRead( weiche[0].buttonPin); if ( weiche[0].currentState == HIGH && weiche[0].lastState == LOW){//if button has just been pressed delay(10);//crude form of button debouncing //toggle the state of the LED if ( weiche[0].ledState == HIGH){ digitalWrite(weiche[0].ledPin, LOW); // weiche.write(minwinkel); weiche[0].servpos = (weiche[0].maxwinkel); for (weiche[0].servpos = weiche[0].maxwinkel; weiche[0].servpos >= weiche[0].minwinkel; weiche[0].servpos -=1)
{servo[0].write(weiche[0].servpos);
delay(servspeed);}
weiche[0].ledState = LOW;
} else {
digitalWrite(weiche[0].ledPin, HIGH);
//weiche.write(maxwinkel);
weiche[0].servpos = weiche[0].minwinkel;
for (weiche[0].servpos=weiche[0].minwinkel; weiche[0].servpos <=weiche[0].maxwinkel; weiche[0].servpos +=1) {servo[0].write(weiche[0].servpos); delay(servspeed);} weiche[0].ledState = HIGH; } } weiche[0].lastState = weiche[0].currentState; weiche[1].currentState = digitalRead( weiche[1].buttonPin); if ( weiche[1].currentState == HIGH && weiche[1].lastState == LOW){//if button has just been pressed delay(10);//crude form of button debouncing //toggle the state of the LED if ( weiche[1].ledState == HIGH){ digitalWrite(weiche[1].ledPin, LOW); // weiche.write(minwinkel); weiche[1].servpos = (weiche[1].maxwinkel); for (weiche[1].servpos = weiche[1].maxwinkel; weiche[1].servpos >= weiche[1].minwinkel; weiche[1].servpos -=1)
{servo[1].write(weiche[1].servpos);
delay(servspeed);}
weiche[1].ledState = LOW;
} else {
digitalWrite(weiche[1].ledPin, HIGH);
//weiche.write(maxwinkel);
weiche[1].servpos = weiche[1].minwinkel;
for (weiche[1].servpos=weiche[1].minwinkel; weiche[1].servpos <=weiche[1].maxwinkel; weiche[1].servpos +=1) {servo[1].write(weiche[1].servpos); delay(servspeed);} weiche[1].ledState = HIGH; } } weiche[1].lastState = weiche[1].currentState; weiche[2].currentState = digitalRead( weiche[2].buttonPin); if ( weiche[2].currentState == HIGH && weiche[2].lastState == LOW){//if button has just been pressed delay(10);//crude form of button debouncing //toggle the state of the LED if ( weiche[2].ledState == HIGH){ digitalWrite(weiche[2].ledPin, LOW); // weiche.write(minwinkel); weiche[2].servpos = (weiche[2].maxwinkel); for (weiche[2].servpos = weiche[2].maxwinkel; weiche[2].servpos >= weiche[2].minwinkel; weiche[2].servpos -=1)
{servo[2].write(weiche[2].servpos);
delay(servspeed);}
weiche[2].ledState = LOW;
} else {
digitalWrite(weiche[2].ledPin, HIGH);
//weiche.write(maxwinkel);
weiche[2].servpos = weiche[2].minwinkel;
for (weiche[2].servpos=weiche[2].minwinkel; weiche[2].servpos <=weiche[2].maxwinkel; weiche[2].servpos +=1) {servo[2].write(weiche[2].servpos); delay(servspeed);} weiche[2].ledState = HIGH; } } weiche[2].lastState = weiche[2].currentState; weiche[3].currentState = digitalRead( weiche[3].buttonPin); if ( weiche[3].currentState == HIGH && weiche[3].lastState == LOW){//if button has just been pressed delay(10);//crude form of button debouncing //toggle the state of the LED if ( weiche[3].ledState == HIGH){ digitalWrite(weiche[3].ledPin, LOW); // weiche.write(minwinkel); weiche[3].servpos = (weiche[3].maxwinkel); for (weiche[3].servpos = weiche[3].maxwinkel; weiche[3].servpos >= weiche[3].minwinkel; weiche[3].servpos -=1)
{servo[3].write(weiche[3].servpos);
delay(servspeed);}
weiche[3].ledState = LOW;
} else {
digitalWrite(weiche[3].ledPin, HIGH);
//weiche.write(maxwinkel);
weiche[3].servpos = weiche[3].minwinkel;
for (weiche[3].servpos=weiche[3].minwinkel; weiche[3].servpos <=weiche[3].maxwinkel; weiche[3].servpos +=1)
{servo[3].write(weiche[3].servpos);
delay(servspeed);}
weiche[3].ledState = HIGH;
}
}
weiche[3].lastState = weiche[3].currentState;
}
